Jinying Transformer / Cast-Resin Dry Type
Cast-Resin Dry Type SC(B)11 / SC(B)13
Cast-resin dry type, 30 to 2500 kVA, HV 6 to 15 kV. No oil, for indoor installation, commercial buildings, data centres and fire-restricted locations.
- Rating30–2500 kVA
- HV6–15 kV
- UseIndoor, commercial buildings, data centres
Three figures that decide indoor installation
Fire class, partial discharge level and operating noise. Together with the insulation class these decide whether the unit may sit anywhere other than a dedicated substation room. State if forced-air cooling is required; fans raise the rating.
SC(B)11
HV 6 / 6.3 / 6.6 / 10 / 10.5 / 11 / 13.2 / 13.8 / 15 kV · LV 0.4 kV · Vector group Yyn0 / Dyn11 · Tapping range ±2 × 2.5 %
| Model | Rating kVA | No-load loss W | Load loss W | Impedance % | Dimensions mm L×W×H | Weight kg |
|---|---|---|---|---|---|---|
| SC(B)11-30/10 | 30 | 171 | 665 | 4 | 680×400×686 | 300 |
| SC(B)11-50/10 | 50 | 243 | 941 | 4 | 690×400×686 | 360 |
| SC(B)11-80/10 | 80 | 324 | 1,302 | 4 | 730×450×796 | 500 |
| SC(B)11-100/10 | 100 | 360 | 1,492 | 4 | 730×500×816 | 600 |
| SC(B)11-125/10 | 125 | 423 | 1,748 | 4 | 780×600×950 | 700 |
| SC(B)11-160/10 | 160 | 486 | 2,014 | 4 | 950×650×1124 | 850 |
| SC(B)11-200/10 | 200 | 558 | 2,394 | 4 | 990×650×1164 | 950 |
| SC(B)11-250/10 | 250 | 648 | 2,613 | 4 | 1020×650×1207 | 1,100 |
| SC(B)11-315/10 | 315 | 792 | 3,287 | 4 | 1050×750×1320 | 1,250 |
| SC(B)11-400/10 | 400 | 873 | 3,781 | 4 | 1100×800×1450 | 1,550 |
| SC(B)11-500/10 | 500 | 1,044 | 4,636 | 4 | 1140×800×1430 | 1,850 |
| SC(B)11-630/10 | 630 | 1,206 | 5,577 | 4 | 1250×800×1500 | 1,900 |
| SC(B)11-800/10 | 800 | 1,368 | 6,603 | 6 | 1330×800×1540 | 2,200 |
| SC(B)11-1000/10 | 1,000 | 1,584 | 7,714 | 6 | 1400×960×1640 | 2,750 |
| SC(B)11-1250/10 | 1,250 | 1,881 | 9,206 | 6 | 1450×960×1690 | 3,300 |
| SC(B)11-1600/10 | 1,600 | 2,205 | 11,144 | 6 | 1560×960×1930 | 4,000 |
| SC(B)11-2000/10 | 2,000 | 2,988 | 13,728 | 6 | 1680×960×1930 | 4,800 |
| SC(B)11-2500/10 | 2,500 | 3,240 | 16,312 | 6 | 1720×1010×1950 | 5,500 |
SC(B)13
HV 6 / 6.3 / 10 kV · LV 0.4 kV · Vector group Yyn0 / Dyn11 · Tapping range ±5 % / ±2 × 2.5 % / +3 −1 × 2.5 %
| Model | Rating kVA | No-load loss W | Load loss W | No-load current % | Impedance % |
|---|---|---|---|---|---|
| SC13-30 | 30 | 135 | 640 | 2.00 | 4 |
| SC13-50 | 50 | 195 | 900 | 2.00 | 4 |
| SC13-80 | 80 | 265 | 1,240 | 1.50 | 4 |
| SC13-100 | 100 | 290 | 1,410 | 1.50 | 4 |
| SC13-125 | 125 | 340 | 1,660 | 1.30 | 4 |
| SC(B)13-160 | 160 | 385 | 1,910 | 1.30 | 4 |
| SC(B)13-200 | 200 | 445 | 2,270 | 1.10 | 4 |
| SC(B)13-250 | 250 | 515 | 2,480 | 1.10 | 4 |
| SC(B)13-315 | 315 | 635 | 3,120 | 1.00 | 4 |
| SC(B)13-400 | 400 | 705 | 3,590 | 1.00 | 4 |
| SC(B)13-500 | 500 | 835 | 4,390 | 1.00 | 4 |
| SC(B)13-630 | 630 | 965 | 5,290 | 0.85 | 4 |
| SC(B)13-630 | 630 | 935 | 5,360 | 0.85 | 6 |
| SC(B)13-800 | 800 | 1,090 | 6,260 | 0.85 | 6 |
| SC(B)13-1000 | 1,000 | 1,270 | 7,310 | 0.85 | 6 |
| SC(B)13-1250 | 1,250 | 1,500 | 8,720 | 0.85 | 6 |
| SC(B)13-1600 | 1,600 | 1,760 | 10,500 | 0.85 | 6 |
| SC(B)13-2000 | 2,000 | 2,190 | 13,000 | 0.70 | 6 |
| SC(B)13-2500 | 2,500 | 2,590 | 15,400 | 0.70 | 6 |
Certification
Certification arranged for the destination country
IEC 60076IEEE/ANSI C57SABS 780ISO 9001
| Destination | HV | LV | Frequency | Conformity scheme |
|---|---|---|---|---|
| Southeast Asia | ||||
| Indonesia | 20 kV | 400 V | 50 Hz | — |
| Philippines | 13.2 kV | 240/480 V | 60 Hz | — |
| Vietnam | 22 kV | 380 V | 50 Hz | — |
| Africa | ||||
| Nigeria | 11 / 33 kV | 415 V | 50 Hz | SONCAP |
| Kenya | 11 / 33 kV | 415 V | 50 Hz | PVoC / KEBS |
| Tanzania | 11 / 33 kV | 400 V | 50 Hz | TBS |
| South Africa | 11 / 22 kV | 400 V | 50 Hz | SABS 780 |
| Egypt | 11 / 22 kV | 400 V | 50 Hz | — |
| Ghana | 11 / 33 kV | 400 V | 50 Hz | — |
| Angola | 15 / 30 kV | 380 V | 50 Hz | — |
| Central Asia | ||||
| Kazakhstan | 6 / 10 kV | 380 V | 50 Hz | — |
| Uzbekistan | 6 / 10 kV | 380 V | 50 Hz | — |
| Latin America | ||||
| Chile | 12 / 23 kV | 380 V | 50 Hz | — |
| Mexico | 13.2 / 23 / 34.5 kV | 220Y/127 V | 60 Hz | NOM-002-SEDE/ENER |
| Colombia | 11.4 / 13.2 / 34.5 kV | 208Y/120 V | 60 Hz | RETIE |
| Peru | 10 / 22.9 kV | 380/220 V | 60 Hz | — |
